Miscellaneous Components

MISCELLANEOUS COMPONENTS LOCATION

Component Location
Cooling Fan Resistor On right front inner fender.
Cruise Control Servo On left rear side of engine compartment. See Figure .
Diagnostic Connector Top front side of engine.
Fuse/Relay Panel Behind panel in passengers footwell. See Figure & Figure .
Ignition Coils (2) Mounted on left and right wheel house walls.
TDC Transmitter On top of clutch bell housing.
