Turning TPMS On

  1. Select menu "TYRE PRESSURE", "SETTINGS, then "SYSTEM".
  2. Using rocker switch, select "ON". See Fig 1.
  3. The display will automatically return to the "SETTINGS" screen. Ensure settings in menu agree with tires mounted on vehicle. Select tire type and tire size (both items must be set).
    NOTE: The system will relearn wheels only if tire type and size have been selected.
Fig 1: TPMS "SYSTEM" Screen
G00225544Courtesy of PORSCHE OF NORTH AMERICA, INC.
