Control Unit (Auto A/C Model)

Control Unit (Auto A/C Model)

Removal
Disconnect the ground cable from battery.
Remove the console front panel.
Remove the center console panel.
Disconnect the connector and aspirator hose (A).

Installation
Install in the reverse order of removal.
