Transmission Control Module (TCM): Installation

Install the TCM.

Tightening torque:

7.5 Nm (0.76 kgf-m, 5.5 ft-lb)

Fig 1: Connecting Connectors To TCM
G03874788Courtesy of SAAB-SCANIA OF AMERICA, INC.
  1. Transmission control module (TCM)
  2. Brake pedal

Connect the connectors to TCM.

Install in the reverse order of removal.
