Accelerator position

The engine control system includes a pedal sensor which gives information on the position of the pedal. This information is accessible on the bus. Pedal position is given in %.

The control module uses information on the pedal position for controlling shifting points and the Lock-up function activation time.

Fig 1: Wiring Diagram - Accelerator Position

Courtesy of SAAB-SCANIA OF AMERICA, INC.
