Cruise Control Connectors

WARNING: This page is about a different car, the 2005 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.

Brake Pedal Position Sensor

Courtesy of GENERAL MOTORS CORP.
Connector Part Information		15332132 3-Way F Global Terminal 150 Series (BK)
Pin	Wire Color	Circuit No.	Function
A	WH	5359	5-Volt Reference
B	YE	5361	Brake Pedal Position Sensor Signal
C	BN	5360	Low Reference

Inflatable Restraint Steering Wheel Module Coil C3

Courtesy of GENERAL MOTORS CORP.
Connector Part Information		15393433 10-Way F Micro 64 Series (BK)
Pin	Wire Color	Circuit No.	Function
A-B	-	-	Not Used
C	PK	339	Ignition 1 Voltage (K34)
D	GY	1884	Cruise Control Switch Signal (K34)
E	D-BU	1796	Steering Wheel Controls Signal (UK3)
F	WH/BK	644	10 Volt Reference (UK3)
G	GY	8	Instrument Panel Lamp Supply Voltage (K34)
H	-	-	Not Used
J	TN	28	Horn Relay Control
K	BK/WH	651	Ground

Steering Wheel Controls - Left (UK3)

Courtesy of GENERAL MOTORS CORP.
Connector Part Information		12103087 7-Way F Molex (BK)
Pin	Wire Color	Circuit No.	Function
1	L-GN	1011	Remote Radio Control Signal
2	GY	8	Instrument Panel Lamp Supply Voltage
3	BK/WH	651	Ground
4	D-BU	1796	Accessory Voltage
5	PK	339	Ignition 1 Voltage
6	GY/WH	397	Cruise Control On Switch Signal

Steering Wheel Controls - Left (w/o UK3)

Courtesy of GENERAL MOTORS CORP.
Connector Part Information		12103499 4-Way F Molex (BK)
Pin	Wire Color	Circuit No.	Function
1	BK/WH	651	Ground
2	GY	8	Instrument Panel Lamp Supply Voltage
3	PK	339	Ignition 1 Voltage
4	GY/WH	397	Cruise Control On Sw

Steering Wheel Controls - Right (UK3)

Courtesy of GENERAL MOTORS CORP.
Connector Part Information		15383018 7-Way F Molex (BK)
Pin	Wire Color	Circuit No.	Function
1	WH/BK	644	10-Volt Reference
2	GY	8	Instrument Panel Lamp Supply Voltage
3	BK/WH	651	Ground
4	D-BU	1796	Accessory Voltage
5	L-GN	1011	Remote Radio Control Signal
6	GY/WH	397	Cruise Control On Switch Signal
7	GY/BK	1884	Cruise Control Switch Signal

Steering Wheel Controls - Right (w/o UK3)

Courtesy of GENERAL MOTORS CORP.
Connector Part Information		12103020 5-Way F Molex (BK)
Pin	Wire Color	Circuit No.	Function
1	BK/WH	651	Ground
2	GY	8	Instrument Panel Lamp Supply Voltage
3	GY/WH	397	Cruise Control On Switch Signal
4	GY/BK	1884	Cruise Control Switch Signal
5	-	-	Not Used
