Cruise Control Component Views
WARNING: This page is about a different car, the 2005 Saturn L300. However, it is still accessible from the selected car via links, so may be relevant.
Callouts For Fig 1
| Callout | Component Name |
|---|---|
| 1 | Cruise Set/Resume Switch |
| 2 | Cruise On/Off Switch |
| 3 | Stop Lamp Switch |
| 4 | Cruise Brake Switch |
| 5 | Cruise Control Module (CCM) |
