Select Lever Rod: Installation

Apply grease to the shaft.
Preparation items:

Grease: NIPPON GREASE NIGTIGHT LTS No. 2 or equivalent

Courtesy of SUBARU OF AMERICA, INC.
Connect the select lever rod with the shaft and the wave washer.
Install the snap pin.
Adjust the select lever. Ref. to CONTROL SYSTEMS>SELECT LEVER>ADJUSTMENT .
Install the center exhaust pipe. Ref. to EXHAUST (H4DO)>CENTER EXHAUST PIPE>INSTALLATION .
