Alternator & Regulator: Description

Alternators are conventional 3-phase alternators utilizing 3 positive and 3 negative diodes to rectify current. Internal Integrated Circuit (IC) voltage regulator controls charging system voltage. See Fig 1.

Fig 1: Alternator Circuit Diagram (Typical)

Courtesy of SUZUKI OF AMERICA CORP.
