Intermediate Drive Shaft Assembly
WARNING: This page is about a different car, the 2007 Suzuki XL7. However, it is still accessible from the selected car via links, so may be relevant.
CALLOUT AND COMPONENT NAME TABLE
| Callout | Component Name |
|---|---|
| 1 | Front Wheel Drive Intermediate Shaft |
| 2 | Front Wheel Drive Intermediate Shaft Bearing Retainers (Qty: 2) |
| 3 | Front Wheel Drive Intermediate Shaft Bearing Assembly Tip: Use a press, with the J 22912-B flat side up, in order to install the bearing assembly. Special Tools J 22912-B Rear Pinion and Axle Bearing Remover |
| 4 | O-Ring |
| 5 | Half Shaft Retainer |
