Kizashi FWD L4-2.4L
>>
Repair and Diagnosis
>>
Body and Frame
>>
Seats
>>
Power Seat Control Module
>>
Locations
>>
Rear
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
Rear
Rear
L: Seat Sensor Wire / M: Trunk Harness, Rear Bumper Wire
L: Seat Sensor Wire (Driver Side) #1
