Ignition-Controlled Automatic Door Lock/Unlock

The RS3200 is factory-set to automatically lock your vehicle's doors when you turn the ignition key to "ON" or "START", and unlock the doors when you turn the key back to "ACC" or "LOCK". To change the programming of this feature, follow the procedure shown below.

G06741938Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
G00501212Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
G00501213Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

The following shows the procedure to replace the batteries in your remote controls. We recommend that you replace the batteries at least once a year, or when the remote control's transmitting range diminishes. You may obtain the replacement battery from your Toyota dealer, as well as many retailers that sell watch batteries. The battery replacement type is a Lithium CR2025.

Important notes on battery replacement:

When replacing the battery, be careful not to lose the components.

Take care not to bend or damage the rubber gasket.
