Health Check: Notes
The Health Check page provides an overview of all ECUs connected in the vehicle. The status of each ECU is provided through a graphic with red/yellow/green status for ECU details. This enables the user to quickly see connection status, software updates and DTC status.
The Health Check page provides access to all ECU operations including:
- ECU Info - Information about the selected ECU,
- Data Flow - Real time data display,
- DTC List - Diagnostic Trouble Codes,
- IO Control - Input Output Direct Control,
- Service - ECU Functions, Identification, Learns and Configuration.
