Accelerator Cable
CAUTION:
Check and adjust idle and maximum speed before making cable adjustments.
Place accelerator pedal in full throttle position. Adjust accelerator cable with adjusting nuts until pump lever freely contacts stop. See Figure . Be sure ball pin on pump lever is pointing upward and touching end of elongated hole. Accelerator cable should be attached at upper hole in bracket.
