SUBFRAME Assembly Overview

NOTE:

The illustration shows a right door hinge. The left door hinge is identical.

Fig 1: Identifying Subframe, Assembly Overview
GWWN57-10122Courtesy of VOLKSWAGEN UNITED STATES, INC.
  1. Subframe
  2. Retaining bracket
  3. Cover caps for assembly opening
    • Quantity: 2
  4. Bolt
    • Quantity: 2
    • Tightening specification: 20 Nm
  5. Bolt
    • Quantity: 10
    • Tightening specification: 8 Nm
  6. Wiring harness
    • To door lock.
  7. Window Regulator Motor
  8. Wiring harness
    • For the exterior mirror.
  9. Connector
    • For door trim wiring harness.
