Replacing the power sun roof switch

Fig 1: Removing Power Sun Roof

Courtesy of VOLVO CARS OF NORTH AMERICA.

Remove the cover over the courtesy lighting switch by lifting the edge with a small screwdriver.

NOTE: The switch spring is not fixed

Reinstall the components in reverse order.

NOTE: The courtesy lighting bulb must be removed when installing the switch (to ensure good contact at the connector pins).
