Steering wheel module (SWM)

Remove the steering wheel and steering column covers. See Replacing the steering column covers

Fig 1: Gear Selector Assembly And Steering Wheel Module

Courtesy of VOLVO CARS OF NORTH AMERICA.

Remove:

• 2 screws
• the connectors
• the control module with stalks and the contact reel by releasing the catches on the underside
• The windscreen wiper and indicator lamp stalks. See Washer / wiper switch, replacing and Turn signal switch, replacing
• the contact reel. See Contact reel / steering wheel angle sensor, replacing

The control module is now exposed.
