Diagnostic Trouble Code (DTC) Information HCM-2283: Notes
Condition
Headlamp Control Module (HCM) receives information about current vehicle configuration from Central electronic module (CEM).
The diagnostic trouble code (DTC) is stored if the control module detects that:
- Vehicle configuration from central electronic module (CEM) is lost.
The control module's test for the diagnostic trouble code (DTC) starts in the event of:
- Activated control module.
NOTE:
The control module can only detect the fault once the test has been started and the diagnostic trouble code (DTC) is stored when the conditions are met.
Substitute Value
- None.
Possible Source
- Fault-trace in transmitting control module.
Fault symptom[s]
- None.
