Checking cable and component

Check the signal cable between rear electronic module (REM) connector terminal #44 (#C4) and hood switch terminal #1. Check for a short-circuit to supply voltage.

Remedy as necessary.

Other information

• See Connecting the breakout box
• See Signal specification
• To disconnect the rear electronic module (REM), see Rear electronic module (REM), replacing
• See Contents

Fig 1: Identifying Connector Terminals

Courtesy of VOLVO CARS OF NORTH AMERICA.

Fig 2: Identifying Ohmmeter

Courtesy of VOLVO CARS OF NORTH AMERICA.

Fig 3: Identifying Hood Switch

Courtesy of VOLVO CARS OF NORTH AMERICA.

• Continue

  Refer to Verification
