Function Test

Fig 1: Identifying Ignition ON

Courtesy of VOLVO CARS OF NORTH AMERICA.

• Ignition on.

  HINT: The inner antennas are connected to the same driver circuit in the keyless vehicle module (KVM).

  Check the inner antenna circuit by clicking on the VCT2000 symbol.

  Fig 2: Identifying VCT2000 Diagnostic Tool Symbol In VIDA

  Courtesy of VOLVO CARS OF NORTH AMERICA.
  Fig 3: Identifying Keyless Vehicle Module

  Courtesy of VOLVO CARS OF NORTH AMERICA.

Was the function OK?

• YES

  Refer to FAULT-TRACING INFORMATION

• NO

  Refer to CHECKING THE WIRING
