Occupant Weight Sensor (OWS) (USA/Can Only)

Courtesy of VOLVO CARS CORPORATION

The Occupant Weight Sensor (OWS) consists of three interactive components:

• Pressure sensor and silicon pad, installed under the seat cushion in passenger seat front.
• Belt tension sensor, mounted in the seat frame on the outside of the front passenger seat.
• Occupant weight sensor module, installed under the front passenger seat.

The pressure sensor and silicon pad are linked with a hose. The pressure sensor registers the pressure to which the seat cushion, that is, the silicon pad, is exposed. For example, when someone is sitting in the seat.

Information from the belt tension sensor is also used to ensure the good performance of the system. The belt tension sensor informs the occupant weight sensor module what force the belt is tensioned with. This is done because the pressure measured by the pressure sensor can be affected by the passenger fastening the seatbelt tightly. This means that the passenger exerts greater pressure on the seat than during normal seatbelt use. The passenger is then interpreted as being heavier than he or she is.

Using information from both the pressure sensor and belt tension sensor, the occupant weight sensor performs calculations that give Supplemental Restraint System Module (SRS) the following information:

• Passenger seat empty  - airbag passenger front off  .
• Passenger seat child  - airbag passenger front off  .
• Passenger seat big  - airbag passenger front on  .

The Occupant Weight Sensor (OWS) transmits continuous signals on the internal controller area network (CAN), which the Supplemental Restraint System Module (SRS) and Occupant Weight Sensor (OWS) are connected to. If the Occupant Weight Sensor (OWS) does not function correctly the Supplemental Restraint System Module (SRS) will:

• disable the front passenger airbag
• light the passenger airbag warning lamp (PAD) in the roof console
• light the SRS (supplemental restraint system) warning lamp and display the alert message in the Driver Information Module (DIM).

If a fault occurs in any of the components the following should be noted:

• The pressure sensor and occupant weight sensor module must be replaced at the same time
• The belt tension sensor is replaced separately.
