General Audio Player Module [2011]: Removal

VEHICLES EARLY VERSION

CAUTION:

Make sure that any disc is removed.

CAUTION:

Make sure to eject the discs one at a time in numerical order, starting with disc No 6 followed by disc No 5.

Courtesy of VOLVO CARS CORPORATION

Remove center console, refer to: CENTER CONSOLE

Courtesy of VOLVO CARS CORPORATION

CAUTION:

Make sure that the fiber optic cables are not bent to a radius of less than 25 mm.

NOTE:

Make sure that the component terminals are not bent or damaged.

VEHICLES LATE VERSION

CAUTION:

Make sure that any disc is removed.

Courtesy of VOLVO CARS CORPORATION

Remove center console, refer to: CENTER CONSOLE

Courtesy of VOLVO CARS CORPORATION

Courtesy of VOLVO CARS CORPORATION

NOTE:

Make sure that the component terminals are not bent or damaged.

NOTE:

Make sure that the optical connectors are clean and free of foreign material.
