Diagnostic Trouble Code (DTC) Information Rem-1D03

Condition

Fig 1: Identifying Central Electronic Module (CEM)

Courtesy of VOLVO CARS CORPORATION

The diagnostic trouble code (DTC) is stored if the rear electronic module (REM) registers that the programming is faulty or incomplete.

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

• None.

Possible Source

• Internal fault in the control module.

Fault symptom[s]

• The fuel gauge does not work
• No locking/unlocking of the tailgate
• Does not lock / unlock the fuel tank filler cap.
