Diagnostic Trouble Code (DTC) Information ECM-930C

Condition

The engine control module (ECM) checks the signal from the clutch pedal sensor. The engine control module (ECM) receives the clutch pedal sensor signal that is sent via the CAN network from the central electronic module (CEM). The diagnostic trouble code (DTC) is stored in the engine control module (ECM) if the clutch pedal sensor signal is missing or incorrect.

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

• The cruise control is disengaged when the fault is active.

Possible Source

Signal too high

• Fault trace the central electronic module (CEM).

Signal too low

• Fault trace the central electronic module (CEM).

Faulty signal

• Fault trace the central electronic module (CEM).

Signal missing

• Fault trace the central electronic module (CEM).

Diagnostic trouble code (DTC) in the central electronic module (CEM)

• Fault trace the central electronic module (CEM).

Fault symptom[s]

• Cruise control does not function at all.
