Checking The Control Module

Fig 1: Identifying Ignition ON

Courtesy of VOLVO CARS CORPORATION

Fig 2: Identifying Connectors

Courtesy of VOLVO CARS CORPORATION

Fig 3: Identifying Control Unit Connected

Courtesy of VOLVO CARS CORPORATION

• Ignition off
• The breakout box connected
• Control module connected.
• Transmission connector disconnected
• Ignition on
• Gear selector in position P.

  Check the circuit for solenoid S2 by connecting an ohmmeter between terminals #68 (#B8) and #53 (#A53). The resistance must be between 7 and 13 kΩ. Try a new control module if the resistance is infinite.

  Remedy as necessary.

  Other information:

  • To connect the breakout box, see CONNECTING THE BREAKOUT BOX
  • To replace the control module, see TRANSMISSION CONTROL MODULE (TCM), REPLACING
  • For information about signals, see SIGNAL SPECIFICATION .
  Fig 4: Identifying Breakout Box

  Courtesy of VOLVO CARS CORPORATION
  Fig 5: Identifying Ohms Display

  Courtesy of VOLVO CARS CORPORATION

Was the resistance incorrect?

• YES

  Refer to VERIFICATION

• NO

  FAULT NOT FOUND:  Troubleshooting has been completed.
