Ignition Coil: Integra
- Turn ignition off. Remove distributor cap. Remove 2 screws to disconnect Black/Yellow and White/Blue wires from terminals "A" and "B", respectively. See Fig 1.
- Resistance between terminals "A" and "B" (primary windings) should be .3-.5 ohms. Resistance between terminal "A" and secondary winding terminal should be 9400-14,600 ohms.
- Resistance is measured at 70°F (20°C). Replace coil if defective.
