Navi ECU
WARNING: This page is about a different car, the 2011 Acura TL, 2010 Acura TL, and 2009 Acura TL. However, it is still accessible from the selected car via links, so may be relevant.
This screen looks for problems in the audio-navigation unit When you initiate this diagnosis, the audio-navigation unit may delay up to a minute while the diagnosis runs
- If D-RAM is NG, replace the audio-navigation unit
- Program Version If displayed, this value represents the version of the navigation software on the audio-navigation unit HDD
- Serial No. should be the same as the serial number found on the underside of the audio-navigation unit You need this number to obtain the security code from the Interactive Network (iN) system
- If Flash is NG, replace the audio-navigation unit
