Repair Procedure: Notes

How to use this Service Information .

G00574679Courtesy of AMERICAN HONDA MOTOR CO., INC.

Review the Service Precautions before doing repairs or service .

NOTE: In the illustration, only one side is shown because the component parts and the removal/installation procedure are the same.
Fig 1: Front Brake Area Replacement Components With Torque Specifications
GHH555034Courtesy of HONDA, U.S.A., INC.
: Torque, N.m (lbf.ft) : Replace : Warning/Caution : Inspection/Adjustment *: Learning ■: SPL Tool : Required Removal
GHH555035Courtesy of HONDA, U.S.A., INC.
: Torque, N.m (lbf.ft) : Replace : Warning/Caution : Inspection/Adjustment *: Learning ■: SPL Tool : Required Removal
*1: Type A
*2: Type B
