Driver's Door Control Module -J386-

Illustration be valid for left and right-hand drive.

Component Location

In Driver's Door -3-.

Pin Arrangements

Courtesy of AUDI OF AMERICA, LLC

1. Driver's Door Control Module -J386-
2. 32-Pin Connector -T32D-, Grey, Connector C
3. 16-Pin Connector -T16F-, Black, Connector B
4. 20-Pin Connector -T20D-, Black, Connector A

Courtesy of AUDI OF AMERICA, LLC
