Rain/Light Recognition Sensor, Wiper Motor Control Module, Vehicle Electrical System Control Module, Garage Door Opener Control Module, Windshield Washer Pump Control Module, Right Front Headlamp, Front Roof Module

Courtesy of AUDI OF AMERICA, LLC

G397

Rain/Light Recognition Sensor

J400

Wiper Motor Control Module

J519

Vehicle Electrical System Control Module

J530

Garage Door Opener Control Module

J1100

Windshield Washer Pump Control Module

MX2

Right Front Headlamp

T3ao

3-Pin Connector, Black

T4q

4-Pin Connector, Black

T5x

5-Pin Connector, Black

T6g

6-Pin Connector, Black

T6o

6-Pin Connector, Black

T8j

8-Pin Connector, Black

T73a

73-Pin Connector, Black, Black

T73b

73-Pin Connector, Black, Naturally Cloudy

WX3

Front Roof Module

B528

LIN Bus Connection 1 (in Main Wiring Harness)

B549

LIN Bus Connection 2 (in Main Wiring Harness)

B699

LIN Bus Connection 4 (in Main Wiring Harness)

For Vehicles with Adaptive Cruise Control (ACC)

Refer to Applicable Wiring Diagram for the Garage Door Opener

For Vehicles with Automatic Dimming Interior Rearview Mirror

For Vehicles with Garage Door Opener

For Vehicles Without Adaptive Cruise Control (ACC)
