Power Windows: CAS: Notes

The Car Access System control unit functions as the master for power window functions:

• Operation by radio remote control key
• Comfort functions (One-Touch)
• Central-locking interface
• Child lock
• Country-specific programming
  Fig 1: Identifying CAS

  Courtesy of BMW OF NORTH AMERICA, INC.
