CBS Correction Vehicle Data

The CBS correction vehicle data allows "quick access" to correct (if improperly input) or change the basic data (stored in the vehicle) for the CBS reset. This includes decreasing the use percentage and number of resets when a reset was mistakenly performed. When the CBS reset is carried out, the changed data in the tester is automatically transferred to the vehicle.

1. CBS correction vehicle data selection 1
   • Correction engine oil
   • Correction microfilter
   • Correction front brakes
   • Correction rear brakes
   • Correction vehicle check
2. CBS correction vehicle data selection 2
   • Correction spark plugs
   • Correction brake fluid
   • Correction coolant
   • Correction Vehicle State Inspection
   • Correction Emission Inspection
3. CBS correction vehicle data selection 3
   • Write telephone numbers
   • Correction date of first registration
4. End
   Fig 1: Displaying CBS Correction Vehicle Data

   Courtesy of BMW OF NORTH AMERICA, INC.
