Button illumination
The footwell module sends the status of the terminal 58g. The seat module receives the status of the terminal 58g via the K-CAN. The seat module passes the status of terminal 58g via the LIN bus to the memory buttons.
Courtesy of BMW OF NORTH AMERICA, INC. COMPONENTS DESCRIPTION CHART
| Index |
Explanation |
| 1 |
M button |
| 2 |
Button 1 |
| 3 |
Button 2 |
