ACP Trouble Code Charts

WARNING: This page is about a different car, the 1995 Cadillac Seville, 1995 Cadillac Eldorado, and 1995 Cadillac DeVille. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: ACP Trouble Code Chart Code A010 (1 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 2: ACP Trouble Code Chart Code A010 (2 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 3: ACP Trouble Code Chart Code A011 (1 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 4: ACP Trouble Code Chart Code A011 (2 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 5: ACP Trouble Code Chart Code A012 (1 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 6: ACP Trouble Code Chart Code A012 (2 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 7: ACP Trouble Code Chart Code A013 (1 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 8: ACP Trouble Code Chart Code A013 (2 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 9: ACP Trouble Code Chart Code A015 (1 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 10: ACP Trouble Code Chart Code A015 (2 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 11: ACP Trouble Code Chart Code A037

Courtesy of GENERAL MOTORS CORP.

Fig 12: ACP Trouble Code Chart Code A040 (1 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 13: ACP Trouble Code Chart Code A040 (2 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 14: ACP Trouble Code Chart Code A047 (1 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 15: ACP Trouble Code Chart Code A047 (2 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 16: ACP Trouble Code Chart Code A048 (1 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 17: ACP Trouble Code Chart Code A048 (2 of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 18: ACP Trouble Code Chart Code A050

Courtesy of GENERAL MOTORS CORP.
