Intake Manifold and Components
WARNING: This page is about a different variant/trim than selected.
| Callout | Component Name |
|---|---|
| 1 | Throttle Body Assembly |
| 2 | Throttle Body Assembly Bolt (Qty: 4) |
| 3 | Throttle Body Gasket |
| 4 | Intake Air Pressure and Temperature Sensor Bolt |
| 5 | Intake Air Pressure and Temperature Sensor |
| 6 | Intake Manifold Assembly |
| 7 | Intake Manifold Assembly Bolt (Qty: 3) |
| 8 | Evaporative Emission Canister Purge Valve |
| 9 | Evaporative Emission Canister Purge Tube Assembly |
| 10 | Intake Manifold Assembly Bolt (Qty: 2) |
| 11 | Intake Manifold Gasket |
