Wiper Switch: Service and Repair

Fig. 4 Windshield wiper switch removal. Models less tilt column:

Fig. 5 Windshield wiper switch removal. Models with tilt column:

1. Remove turn signal switch as outlined under ``Turn Signal Switch, Replace'' procedure.
2. Refer to Figs. 4 and 5 for wiper switch replacement.
