Removal Procedure

WARNING: This page is about a different car, the 2002 Cadillac Eldorado. However, it is still accessible from the selected car via links, so may be relevant.

Raise the drivers seat to the full forward and upward position.
Position outward the seat spring wires (2) retaining the memory seat module to the seat bottom cushion frame.
Disconnect the electrical connectors.
Remove the memory seat module (1).

Fig 1: Identifying Seat Spring Wires & Memory Seat Module
Courtesy of GENERAL MOTORS CORP.
