Removal Procedure

  1. Remove the rear shaft panel.
    2. Fig 1: Rear Shaft Panel
    GM615685Courtesy of GENERAL MOTORS COMPANY
  2. Remove the fasteners retaining the child restraint tether anchors (1, 2) to the cross car beam that are being serviced.
  3. Remove the child restraint tether anchors center (1), outboard (2) from the vehicle.
    Fig 2: Child Restraint Tether Anchors & Fasteners
    G01666280Courtesy of GENERAL MOTORS CORP.
