Removal Procedure

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2003 GMC Savana Special, 2003 GMC Savana Camper Special, 2003 GMC Savana, 2003 Chevrolet RV Cutaway, and 2003 Chevrolet Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front door trim plate. Refer to Door Trim Plate Replacement - Front .
  2. Remove the electrical connector (3) from the power window switch.
  3. Release the clip from the front door trim plate (1) in order to remove the escutcheon from the trim plate (1).
  4. Release the tabs on the power window switch (10) in order to remove the power window switch (10) from the trim plate.
    Fig 1: Removing Power Window Switch
    G02423026Courtesy of GENERAL MOTORS CORP.
