Instrument Panel Multifunction Switch Replacement

Fig 1: Instrument Panel Multifunction Switch

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure  Remove the instrument panel center trim panel. Refer to Instrument Panel Center Trim Panel Replacement .
1	Instrument Panel Multifunction Switch Procedure  Using the appropriate tool, depress tabs on switch and gently remove from panel.
