Windshield Washer Solvent Container Level Sensor Replacement
WARNING: This page is about a different car, the 2018 Cadillac XTS. However, it is still accessible from the selected car via links, so may be relevant.
| Callout |
Component Name |
Preliminary Procedure
Remove the left front wheelhouse front liner. Refer to Front Wheelhouse Front Liner Replacement |
| 1 |
Windshield Washer Solvent Level Sensor Procedure
- Disconnect the electrical connector from the windshield washer solvent level sensor.
- Place a clean suitable drain pan under the windshield washer solvent container to secure the windshield washer solvent when the level sensor and seal are removed.
- Using two flat-bladed tools, place the ends of the flat blades under each side of the windshield washer solvent level sensor seal.
- Twisting in opposite directions, pry outward, the level sensor from the washer solvent container.
- Remove and discard the windshield washer level sensor seal and replace with new.
|
