Temperature Sensor

Firewall components & LH side of V6-262/4.3L:




RH Rear Of Engine

Applicable to: 3L engine. 1987 R & V series

Firewall components & RH side of V6-262/4.3L:




RH Front Of Engine

Applicable to: 3L engine. 1987 R & V series
