Installation Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.

Attach the electrical connector to the CD changer.
Install the CD changer assembly into the center console.
NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
Install the front CD changer assembly retaining screws (1).
Tighten

Tighten the front CD changer assembly retaining screws to 1.9 N.m (17 lb ft).
Install the rear CD changer assembly retaining screw.
Tighten

Tighten the rear CD changer assembly retaining screw to 2.5 N.m (22 lb ft).
Close the center armrest.

Fig 1: Remote CD Player
Courtesy of GENERAL MOTORS CORP.
