Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Montana, 2003 Oldsmobile Silhouette, and 2003 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the instrument panel (IP) upper trim. Refer to TRIM PAD REPLACEMENT - INSTRUMENT PANEL (I/P) UPPER  in Instrument Panel, Gages and Console.
  2. Disengage the retaining tabs in order to remove the door lock receiver from the IP upper trim.
  3. Disconnect the electrical connector from the door lock receiver.
    Fig 1: Disconnecting Electrical Connector From Door Lock Receiver
    G01534606Courtesy of GENERAL MOTORS CORP.
