Removal Procedure
- Remove the front door trim plate (1). Refer to Door Trim Plate Replacement - Front .
- Remove the electrical connector (2) from the power mirror switch (9).
- Release the clip that retains the power mirror switch (9) to the front door trim plate (1).
- Remove the power mirror switch (9) from the front door trim plate (1).
