Scan Tool Data Definitions
8 Digit GM Part Number: The scan tool displays an 8 digit alphanumeric number. The part number of the module.
Antenna Signal: The scan tool displays 0 - 300. The signal from the antenna is measure in dBuV.
Auto. Set: The scan tool displays Active/Inactive. Whether or not the Auto Set feature is currently active.
Band Number: The scan tool displays AM/FM/FM1. The current band that the radio is in.
Calibration ID: The scan tool displays 0 - 9999. The number designating what calibrations the radio contains.
Cassette Cut Tape: The scan tool displays 0 - 999. The number of cut tape errors the radio has recorded.
Cassette Load/Unload Errors: The scan tool displays 0 - 999. The number of cassette tight tape errors the radio has recorded.
CD Changer: The scan tool displays Yes/No. The module displays Yes when the CD changer is present.
CD Focus Errors: The scan tool displays 0 - 999. The number of CD focus errors the radio has recorded. 0 - 999. The number of CD loading and unloading errors the radio has recorded.
CD Tracking Errors: The scan tool displays 0 - 999. The number of CD tracking errors the radio has recorded.
Component Serial # 13-1: The scan tool displays 0 - 9. The internal programming codes of the module.
Component Serial # 17-1: The scan tool displays 0 - 9. The internal programming codes of the module.
Driver Number: The scan tool displays 1 - 2. The memory position the driver has selected as received by Class 2 lines.
Julian Date of Build: The scan tool displays 0 - 999. The month and year that the module was built.
PROM ID: The scan tool displays 0 - 999. The identification number of the radios internal PROM.
Preset Control: The scan tool displays a Preset 1 - 6. The preset number when the radio is on a present station.
Theft Armed: The scan tool displays Yes/No. The Scan tool displays Yes when the theft mode has been turned ON by recognizing a valid VIN #.
Theft Lock: The scan tool displays Yes/No. The scan tool displays Yes when the radio receives the incorrect VIN number from the PCM across Class 2 lines.
Total Cassette Hours: The scan tool displays 0 - 999 hrs. The total number of hours the cassette player has been used.
Total CD Hours: The scan tool displays 0 - 999 hrs. The total number of hours the CD player has been used.
Total Radio Hours: The scan tool displays 0 - 999 hrs. The total number of hours the radio has been used.
Year Module Built: The scan tool displays a 1990 - 2020. The production year the module was manufactured.
