Steering Wheel and Column Component Views
Fig 1: Identifying Steering Wheel And Column Components
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
1
Stop Lamp Switch
2
Automatic Transmission (A/T) Select Lever
3
Ignition Lock Cylinder Control Actuator
4
Ignition Key Cylinder
