Engine Identification

WARNING: This page is about a different car, the 2005 Saturn L300. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Locating Vehicle Identification Number (VIN)
GM797514Courtesy of GENERAL MOTORS CORP.

The Vehicle Identification Number (VIN) Derivative (2) is located on the lower right side of the engine block and is a nine digit number stamped or laser etched onto the engine at the vehicle assembly plant. If reading the identification number from the left, the following information can be obtained:

Engine displacement (1) is cast into the engine block under the starter motor.
