Ambient Light Sensor Replacement

WARNING: This page is about a different car, the 2007 Pontiac Torrent and 2007 Chevrolet Equinox. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Locating Ambient Light Sensor
GM1719468Courtesy of GENERAL MOTORS CORP.
Ambient Light Sensor Replacement

Callout Component Name
1 Instrument Panel Trim Panel
Procedure:
Remove the instrument panel upper trim pad. Refer to Instrument Panel Upper Trim Panel Replacement .
2 Ambient Light Sensor
Tip:  Twist and pull down to remove the sensor.
