Installation ProcedureFuel Hose/Pipes Assembly Replacement

    Fig 1: View of FTP Sensor
    GM1376165Courtesy of GENERAL MOTORS CORP.
  1. Clean the gasket mating surface on the fuel tank.
  2. Position the new gasket in place.
  3. Install the fuel pump into the fuel tank in the same location as removed for ease of line and connector installation.
  4. Install the fuel pump assembly clip.
  5. Connect the fuel pump assembly connector.
  6. Install the fuel pump line.
  7. Install the fuel pump access cover.
  8. Install the EF10 fuse.
  9. Connect the negative battery cable.
  10. Perform an operational check of the fuel pump.
  11. Install the rear seat. Refer to Rear Seat Cushion Replacement .
